Can You Ceiling Mount a Curtain Track? What You Need to Know About Fixings and Joists

Ceiling mounting a curtain track can create a clean, practical finish, but what happens when you need to work around ceiling joists and existing fixing points? In this article, we look at a real customer project to explain how ceiling-mounted curtain tracks are fixed, what top fixing means, how far apart fixings may need to be, and what to consider when choosing tracks for voile and heavier curtains.

The customer’s question: can I fix my curtain track to the ceiling?

The customer was planning a wall-to-wall curtain arrangement across a straight span of just over four metres.

Rather than a single curtain, the plan involved two layers: a lighter voile and a heavier main curtain. He was also considering using two separate tracks so there would be more flexibility over the distance between the two sets of curtains.

The preferred look was for the curtains to sit as high as possible, potentially with moulding positioned in front of the tracks to disguise them.

There was one practical concern: could the curtain tracks be ceiling mounted when the joists were spaced apart?

It’s a useful question to ask before ordering.

What about ceiling joists?

One of the customer’s main concerns was whether the position of the ceiling joists would make top fixing difficult.

It’s a sensible question, particularly when you’re working with an existing ceiling rather than planning the curtain tracks as part of a new build or renovation.

For the Silent Gliss 1080 and SG1280 discussed during the call, the manufacturer’s technical information specifies top-fix brackets positioned 100mm from each end of the track, with further fixing points at a maximum of 600mm centres along the track.

That detail was particularly helpful in this case. The customer explained that his ceiling joists were approximately 60cm apart, so knowing the recommended fixing centres gave him a much clearer starting point for planning the installation.

It’s important, however, to think about two things separately: the fixing intervals required by the curtain track and what you’re actually fixing the track into.

Before installation, establish where suitable fixing points are available in your ceiling and whether they provide an appropriate fixing for your chosen track and curtain arrangement. The manufacturer’s fitting instructions for the specific track should always be followed.

For this customer, checking the fixing requirements helped answer one of the biggest questions he had at the start of the call: ceiling mounting wasn’t something he necessarily needed to rule out simply because the joists were spaced apart.

Top fix vs face fix: what’s the difference?

The terminology can make curtain track installation sound more complicated than it needs to be.

Put simply:

Top fix means fitting the curtain track to the ceiling.
Face fix means fitting the curtain track to a wall.

This was another question that came up during the conversation. Once the customer understood that top fix referred to ceiling mounting and face fix to wall mounting, choosing the appropriate fixing arrangement became much easier.

Both the Silent Gliss SG1080 and SG1280 discussed for this project offer top-fix options, so the customer could continue planning around his preferred ceiling-mounted arrangement.

Which ceiling-mounted curtain tracks were considered?
For this project, two different Silent Gliss hand-operated tracks were discussed.

The Silent Gliss SG1080 was suggested for the lighter voile curtain, while the Silent Gliss SG1280 was discussed for the heavier main curtain.

The customer had originally considered a double-track system, but the amount of fabric also raised another question: would there be enough room between the two channels when the curtains were stacked?

Using two individual tracks offered more flexibility because their position – and therefore the space between the voile and main curtain – could be planned separately.

For the heavier curtain, the conversation also covered the option of roller gliders to help provide smooth movement along the track.

Why choose a ceiling-mounted curtain track?

For this customer, ceiling mounting wasn’t simply an installation decision. It was also part of the finished look he wanted to achieve.

He wanted the curtains positioned close to the ceiling and was considering replacing moulding in front of the tracks so that much of the hardware would be hidden.

It’s a good example of why track position is worth considering early in a curtain project. The fixing method, curtain heading, amount of fabric, space between tracks and where the curtains will stack when open can all influence the final arrangement.

What about curtain tracks over four metres long?

The wall-to-wall span in this project was a little over four metres, which led to another practical question: would the tracks arrive in one piece?

During the call, the customer was advised that anything over four metres would be supplied in two parts.

There were two practical reasons discussed: getting a very long track through the distribution network and then getting it into the property and into position for installation.

Supplying the track in two sections makes handling easier, with the sections connected as part of the installation.

It’s another useful detail to consider when planning a long wall-to-wall track, particularly before assuming that a track over four metres will arrive as one continuous length.

Start with the track, then work through the details

One of the most useful things about this particular call was the customer’s determination not to become distracted by every decision at once.

His approach was simple: establish which tracks could work, understand how they would be fixed, and then move on to details such as track spacing, curtain hooks and draw rods.

That’s a sensible way to approach a project with several decisions to make.

By the end of the conversation, the customer had a much clearer idea of the two tracks he wanted to consider, how they could be ceiling mounted and what he needed to check before ordering.

He summed up the experience simply:

“This has been a very helpful phone call.”

If you’re considering a ceiling-mounted curtain track and aren’t sure where to start, check the fixing requirements for the particular track alongside the construction of your ceiling before ordering.

For more complex made-to-measure curtain track requirements, our team can help with product selection and specification, alongside professional bending services and excellent craftsmanship for made-to-measure solutions.
